1.5 Specifications

Below are the specifications for the Apollo III motion controller.
Item
Input Power
Max Power Consumption
Axes
Step and Direction Axis Control
Connection
Max Pulse Speed
Encoder Feedback
Connection
Max Frequency
Spindle
Relay Outputs
Analog Signal
Encoder Feedback
Outputs
Voltage
Max Current
Commons
Inputs
Voltage
Min Current
Isolated
Enable Circuit
Hardware Enable
Drive Enable
Emergency Stop Circuit
Ethernet Port
Dimensions
Optimal Temperature Range
TABLE 2 - SPECIFICATIONS FOR THE APOLLO III MOTION CONTROLLER
Apollo III Using Mach3
Specification
24VDC
48W
6
5V Single Ended and Differential
RJ45 Connectors and Terminal Blocks
1.6 MHz
5V Differential
RJ45 Connectors
6.25 MHz
1
Clockwise (CW) and Counterclockwise (CCW)
0-10VDC
5V Differential
8
7V-48VDC*
250mA**
2
16 (Sinking or Sourcing)
2.5V-48VDC
2mA
Optional
2
Relay Contacts, 5V Enable, 24V Enable
Relay Contacts
Normally Closed Connection
10/100 MHz
8.32"(L) X 5.75"(W) X 2"(H)
32° to 100°F (0° to 38°C)
