Network Management Port Status Indicators

The server has one 10/100/1000BASE-T Ethernet management domain interface, labeled NET
MGT. There are two status indicators (LEDs) on this port. These indicators are visible from the
back of the server.
Status Indicator
Name
Activity
Link speed

Ethernet Port Status Indicators

The server has one Gigabit Ethernet port (NET 0). There are two status indicators (LEDs) that
are visible from the back of the server.
Status Indicator
Name
Activity
Link speed
32 Oracle Server X7-2L Service Manual • October 2017
Icon Color
Amber
Location Color
Top right Green
Top left Green
Location Color
Top left Green
Top right Bi-colored:
Amber/Green
State and Meaning
■ SLOW BLINK – Normal operation. Input power
is within specification. DC output voltage is not
enabled.
■ STEADY ON – Normal operation. Input AC power
and DC output voltage are within specification.
■ OFF – Normal operation. No service action is
required.
■ STEADY ON – The power supply (PS) detected a PS
fan failure, PS overtemperature, PS over current, or
PS over or under voltage.
State and Meaning
■ ON – Link up.
■ OFF – No link or down link.
■ FLASHING – Packet activity.
■ ON – 1000BASE-T link.
■ OFF – 10/100BASE-T link.
State and Meaning
■ ON – Link up.
■ OFF– No activity.
■ FLASHING – Packet activity.
■ OFF – 100BASE-T link (if link up).
■ Green ON – 1000BBASE-T link.
