Editing Parameters
Note
56
Type
Door SW 2NC (See note 1.)
Door SW 1NC/1NO (See note 1.)
Door SW 1NC
Limit SW 2NC (See note 1.)
Limit SW 1NC/1NO (See note 1.)
Limit SW 1NC
Enable SW 2NO (See note 1.)
Enable 2NO 2NO (See note 2.)
Two Hand Switch (See note 1.)
Other 2NC (See note 1.)
Other 2NO (See note 1.)
Other 1NC/1NO (See note 1.)
Other 1NO/1NC (See note 1.)
Other 1NC (Single Contact)
SLC 2 outputs (See note 1.)
SLC 1 output
Other PNP 2 outputs (See note 1.)
Other PNP output
Reset SW
Feedback (EDM input)
Standard SW
Not Use
(1) Can be selected only when the terminal number is an even number.
(2) Can be selected only when the terminal number is an even number and
there are at least four remaining terminals.
5. Click the Next Button. If there are output terminals (e.g., DST1-MD16SL-
1), the following dialog box will be displayed.
Section 3-1
Description
Specify to use two inputs (both NC) from
a door switch.
Specify to use two inputs (NC and NO)
from a door switch.
Specify to use one input from a door
switch.
Specify to use two inputs (both NC) from
a limit switch.
Specify to use two inputs (NC and NO)
from a limit switch.
Specify to use one input from a limit
switch.
Specify to use two inputs from an enable
switch.
Specify to use four inputs from an enable
switch.
Specify to use two inputs from a two hand
switch.
Specify to use input from other 2-NC
devices.
Specify to use input from other 2-NO
devices.
Specify to use input from other NC/NO
devices.
Specify to use input from other NO/NC
devices.
Specify to use other 1-NC devices.
Specify to use two inputs from a light cur-
tain.
Specify to use one input from a light cur-
tain.
Specify to use two inputs from other
semiconductors.
Specify to use one input from other semi-
conductors.
Specify to use inputs from a reset switch.
Specify to use as feedback signal to
EDM.
Specify to use inputs from a switch for
non-safety applications.
Specify to not use the input.
