DeviceNet Explicit Messages
Setting Hold/Clear for Communications Errors (Test Output)
Explicit Read
message /write
Setting for Out- Read Reads whether hold
put Status (Hold
or Clear) after
Communications
Error
Setting for Out- Write Sets either hold or
put Status (Hold
or Clear) after
Communications
Error
Note The default setting is for all outputs to be cleared (0).
Writing Maintenance Information
Explicit Read
message /write
Maintenance Save
Counter Save
Function
Service
Code
0E hex
or clear is set as the
output status after a
communications error
for the output (1 to 4)
specified by the
instance ID. The set-
ting can be read for a
specified number of
points.
10 hex
clear as the output
status after a commu-
nications error for an
output (1 to 4) speci-
fied by the instance
ID. The setting can be
read for a specified
number of points.
Function
Service
Code
Records the mainte- 16 hex
nance counter in the
Slave's memory
Command
Class Instance Attribute
ID ID ID
09 hex 01 to 04 05 hex
hex
09 hex 01 to 04 05 hex
hex
Command
Class Instance Attribute
ID
ID ID
95 hex 01 hex -
Appendix 1
Response
Data size
- 1 byte
00 hex: Clear
01 hex: Hold
1 byte
00 hex:
Clear
01 hex:
Hold
Response
Data size
- -
