Maintenance Functions of DST1-series Safety I/O Terminals
Monitoring Using the Network Configurator
36
The user can monitor the counts for safety input status, test output status, and
safety output status using any of the following methods:
1. Select a device and select Device - Maintenance Information from the
menu bar.
2. Select a device and click the Maintenance Information Button on the tool-
bar.
3. Right-click a device and select Maintenance Information from the pop-up
menu.
4. Select a device and select Device - Monitor from the menu bar. Click the
Maintenance Tab in the displayed window.
5. Select a device and click the Monitor Device Button on the toolbar. Click
the Maintenance Tab in the displayed window.
6. Right-click a device and select Monitor from the pop-up menu. Click Main-
tenance Tab in the displayed window.
Each counter can be cleared. Select the counter to clear and click the Clear
Value Button.
Section 1-7
