DeviceNet Explicit Messages
Explicit Read
message /write
Output Monitor Read Reads the set value
Status for Total for the total ON
ON Time or time or number of
Contact Opera- contact operations
tion Counter (unit: operations) of
Read the output (1 to 4)
specified by the
instance ID.
Safety Output Read Reads the cause
Cause of Error for the normal flag
Information (1 to 8) specified by
Read the Instance ID
turning OFF.
Function
Service
Code
0E hex 09 hex 01 to 04
0E hex 09 hex 01 to 04
Command
Class Instance Attribute
ID ID ID
67 hex
hex
76 hex
hex
Appendix 1
Response
Data size
- 1 byte
00 hex: Within
range
01 hex: Over
range (over the
monitor value)
0 = No error
01 hex: Con-
figuration invalid
02 hex: Over-
load detected
05 hex: Output
ON error
06 hex: Current
limit detection
