Preface - Texas Instruments TMS320C28 series Reference Manual

This document describes the CPU architecture, pipeline, instruction set, and interrupts of the C28x
floating-point DSP.
About This Manual
The TMS320C2000™ digital signal processor (DSP) platform is part of the TMS320™ DSP family.
Notational Conventions
This document uses the following conventions.
• Hexadecimal numbers are shown with the suffix h or with a leading 0x. For example, the following
number is 40 hexadecimal (decimal 64): 40h or 0x40.
• Registers in this document are shown in figures and described in tables.
– Each register figure shows a rectangle divided into fields that represent the fields of the register.
Each field is labeled with its bit name, its beginning and ending bit numbers above, and its
read/write properties below. A legend explains the notation used for the properties.
– Reserved bits in a register figure designate a bit that is used for future device expansion.
Related Documentation
The following books describe the TMS320x28x and related support tools that are available on the TI
website:
Data Manual and Errata—
SPRS439— TMS320F28335, TMS320F28334, TMS320F28332, TMS320F28235, TMS320F28234,
TMS320F28232 Digital Signal Controllers (DSCs) Data Manual
descriptions, as well as electrical and timing specifications for the F2833x/2823x devices.
SPRZ272— TMS320F28335, F28334, F28332, TMS320F28235, F28234, F28232 Digital Signal
Controllers (DSCs) Silicon Errata
silicon.
CPU User's Guides—
SPRU430— TMS320C28x DSP CPU and Instruction Set Reference Guide
processing unit (CPU) and the assembly language instructions of the TMS320C28x fixed-point
digital signal processors (DSPs). It also describes emulation features available on these DSPs.
SPRUEO2— TMS320C28x Floating Point Unit and Instruction Set Reference Guide
floating-point unit and includes the instructions for the FPU.
Peripheral Guides—
SPRU566— TMS320x28xx, 28xxx Peripheral Reference Guide
of the 28x digital signal processors (DSPs).
SPRUFB0— TMS320x2833x, 2823x System Control and Interrupts Reference Guide
various interrupts and system control features of the 2833x digital signal controllers (DSCs).
SPRU812— TMS320x2833x, 2823x Analog-to-Digital Converter (ADC) Reference Guide
configure and use the on-chip ADC module, which is a 12-bit pipelined ADC.
