MOV32 *(0:16bitAddr), loc32
Operands
0:16bitAddr
loc32
Opcode
LSW: 1011 1101
MSW: IIII IIII
Move the 32-bit value in loc32 to the memory location addressed by 0:16bitAddr. The
Description
EALLOW bit in the ST1 register is ignored by this operation.
[0:16bitAddr] = [loc32]
This instruction does not modify any STF register flags.
Flags
Flag
Modified
This is a two-cycle instruction.
Pipeline
Example
MOV32 mem32, RaH
See also
MOV32 mem32, STF
MOV32 loc32, *(0:16bitAddr)
SPRUEO2A – June 2007 – Revised August 2008
Submit Documentation Feedback
Move the Contents of loc32 to Memory
16-bit immediate address, zero extended
32 bit source location
loc32
IIII IIII
TF ZI
No No
MOVIZ R5H, #0x1234
MOVXI R5H, #0xABCD
NOP
MOV32 ACC, R5H
MOV32 *(0xA000), @ACC ; [0x00A000] = ACC
NOP
NI ZF NF
No No No
; R5H[31:16] = 0x1234
; R5H[15:0] = 0xABCD
; 1 Alignment Cycle
; ACC = 0x1234ABCD
; 1 Cycle delay for MOV32 to complete
; <-- MOV32 *(0:16bitAddr), loc32 complete,
; [0x00A000] = 0xABCD, [0x00A001] = 0x1234
Instructions
LUF LVF
No No
Instruction Set 79
