Appendix B: Vehicle Power Management Setup
Vehicle Power Management Setup
Startup and Shutdown Voltage Setting
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Power Management Configuration
** External +5V & +12V Power Setting **
External Power [Turn Off Both]
** Startup & Shutdown Voltage Setting **
Input Voltage 24 V
[(11.5,10.5)/(23,21)]
Startup,Shutdown
**Delay Time Setting**
Startup,Shutdown
Power On Delay
(11.5,10.5)/(23,21)
(12.0,11.0)/(24,22)
Power Off Delay
(12.5,11.0)/(25,22)
(12.5,11.5)/(25,23)
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved
2.
If the input voltage setting is 24V :
Startup,Shutdown Setting
set the startup voltage to 23V and the shutdown voltage to 21V.
If the input voltage setting is 24V :
set the startup voltage to 24V and the shutdown voltage to 22V.
If the input voltage setting is 24V :
set the startup voltage to 25V and the shutdown voltage to 22V.
If the input voltage setting is 24V :
→←: Select Screen
↑↓: Select Item
set the startup voltage to 25V and the shutdown voltage to 23V.
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
