Chapter 3: Jumpers and Connectors

Serial-ATA

Connector size: Standard Serial ATA 7P (1.27mm, SATA-M-180)
Connector location: CN3
1 7
Pin Definition
1 GND
3 SATA0_TXN
5 SATA0_RXN
7 GND
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved
Pin Definition
2 SATA0_TXP
4 GND
6 SATA0_RXP

SATA DOM Power Connector

Connector size: 1x2 2-pin header, 1.25mm pitch
Connector location: J9
1 2
Pin Definition
1 GND
2 VCC5
22
VMC 1100 User Manual
