Chapter 3: Jumpers and Connectors

Internal Connectors and DIP Switch Settings

VGA Connector

Connector size: 1x10 10-pin header, 1.0mm pitch
Connector location: J2
10 1
Pin Definition
1 VGA_+5V
3 VGA_DATA
5 VGA_HS
7 VGA_BLUE
9 VGA_RED
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved
Pin Definition
2 VGA_CLK
4 VGA_VS
6 GND
8 VGA_GREEN
10 GND

Flash/Debug Connector

Connector size: 1x24 24-pin wafer, 1.0mm pitch
Connector location: J1
24
Pin Definition
1 GND
3 EC_KSI5
5 EC_KSI3
7 EC_KSI1
9 GND
11 GND
13 GND
15 EC_KSO9
17 EC_KSO7
19 EC_KSO5
21 EC_KSO3
23 EC_KSO1
19
1
Pin Definition
2 GND
4 EC_KSI4
6 EC_KSI2
8 EC_KSI0
10 GND
12 GND
14 EC_KSO10
16 EC_KSO8
18 EC_KSO6
20 EC_KSO4
22 EC_KSO2
24 EC_KSO0
