Chapter 3: Jumpers and Connectors

EC Debug COM Connector

Connector size: 1x3 3-pin header, 1.0mm pitch
Connector location: J6
1 3
Pin Definition
1 RX
2 GND
3 TX
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved

Port 80 Debug Connector

Connector size: 1x10 10-pin header, 1.0mm pitch
Connector location: J8
10 1
Pin Definition
1 GND
3 33M_CLK
5 LPC_AD3
7 LPC_AD1
9 VCC3
21
Pin Definition
2 PCIRST#
4 LPC_FRAME#
6 LPC_AD2
8 LPC_AD0
10 VCC3
