Appendix A: I/O Address Function
Bit5: Wake on RTC MODULE
0: DISABLE(*)
1: ENABLE
Bit6: Power on/off CAN/CAN2 BUS MODULE
0: OFF
1: ON(*)
Bit7: Status of COM PORT (for COM4 switch)
0: GPS (*)
1: MCU Download
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved
8. Delay Time Setting
I/O port : 0EE7H
Bit7: Power On Delay
0: DISABLE(*)
1: ENABLE
Bit6: Power Off Delay
0: DISABLE(*)
1: ENABLE
Delay On Time Setting
BIT5~3 Time
000 10 sec
001 30 sec
010 1 min
011 5 min
100 10 min
101 15 min
110 30 min
111 1 hour
76
Delay Off Time Setting
BIT2~0 Time
000 20 sec
001 1 min
010 5 min
011 10 min
100 30 min
101 1 hour
110 6 hour
111 18 hour
