Appendix A: I/O Address Function
9. Startup and Shutdown Voltage Control
I/O port : 0EE8H
Only set by switch on motherboard(read only)
BIT3~2 Input Voltage
11 12V
10 24V
01 6~36V
00 6~36V
When input voltage 12V
BIT1~0 Input Voltage 12V
00 Startup
11.5V
01 Startup
12V
10 Startup
12.5V
11 Startup
12.5V
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved
When input voltage 24V
BIT1~0
Shutdown 00
10.5V
Shutdown 01
11V
Shutdown 10
11V
Shutdown
11
11.5V
Input Voltage 24V
Startup Shutdown
23V 21V
Startup Shutdown
24V 22V
Startup Shutdown
25V 22V
Startup Shutdown
25V 23V
