Appendix G: Changing COM Mode (RS232/RS485)

a g: C
PPendIx
When the customer wants to change the setting of the COM to either
RS232 or RS485, please go to "COM Mode" → "COM 2 SWITCH" in the
"Advanced" menu of the BIOS as shown below.
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced Boot Security
WWAN Module [Enabled]
Wake On WWAN Module [Enabled]
WWAN Digital Voice [HE910(I2S)]
RTC Alarm Time [Disabled]
Brightness Mode [Menu Mode]
COM 2 SWITCH
COM Mode [RS232]
Power Button [En
Power Button Mode [Sh
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved
C
hangIng om
Save & Exit
COM Mode - RS232/RS485
switch
COM Mode
RS485
RS232
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
