Diagnostic Guide for ProCurve 9300/9400 Series Routing Switches
To display the index range for each kind of CAM entry, enter the following command:
ProCurveRS# show cam-partition detail
==== SLOT 1 CAM PARTITION ====
DMA: 0 (0x00)
Number of CAM devices per DMA:
Number of hw entries per CAM:
Total size of CAM = 1Mbits
complete CAM index range per DMA:
(sw) 1 - 16383
(hw) 0 - 16383
Percentage of CAM hardware entries for each partition:
Level3 l3 = 2047 (0.124938Mbits)
Level3 l3 = 2048 (0.125Mbits) (12.5%)
Level3 l3 = 8192 (0.5Mbits)
Level4 = 4096 (0.25Mbits)
L3 level 3 index range:
(sw) 1 - 2047
(hw) 1 - 2047
L3 level 2 index range:
(sw) 2048 - 4095
(hw) 2048 - 4095
L3 index range:
(sw) 4096 - 12287
(hw) 4096 - 12287
L4 pool 0 index range:
(sw) 12288 - 14335
(hw) 12288 - 14335
L2/L4 pool 1 index range:
(sw) 14336 - 16383
(hw) 14336 - 16383
Syntax: show cam-partition detail
To display CAM partitioning information for a specified module, enter a command such as the following:
ProCurveRS# show cam-partition module 3 brief
==== SLOT 3 CAM PARTITION ====
DMA: 8 (0x08)
Number of CAM devices per DMA:
Number of hw entries per CAM:
Total size of CAM = 0.9375Mbits
complete CAM index range per DMA:
(sw) 1 - 15359
(hw) 0 - 15359
Percentage of CAM hardware entries for each partition:
Level3 l3 = 2047 (0.124938Mbits)
Level3 l3 = 2048 (0.125Mbits) (13.333333%)
Level3 l3 = 8192 (0.5Mbits)
Level4 = 3072 (0.1875Mbits)
Syntax: show cam-partition module <module> brief | detail
5 - 6
8
0x00800
(1 - 0x03fff), total entries: 16383 (0x03fff)
(0 - 0x03fff), total entries: 16384 (0x04000)
(50%)
(25%)
(0x00001 - 0x007ff), free 2047 (0x007ff)
(0x00001 - 0x007ff)
(0x00800 - 0x00fff), free 2048 (0x00800)
(0x00800 - 0x00fff)
(0x01000 - 0x02fff), free 8189 (0x01ffd)
(0x01000 - 0x02fff)
(0x03000 - 0x037ff), free 2044 (0x007fc)
(0x03000 - 0x037ff)
(0x03800 - 0x03fff), free 2047 (0x007ff)
(0x03800 - 0x03fff)
8
0x00800
(1 - 0x03bff), total entries: 15359 (0x03bff)
(0 - 0x03bff), total entries: 15360 (0x03c00)
(53.333333%)
(12.493896%)
(13.326822%)
(20%)
June 2005
