After you enter this command, messages such as the following appear at the destination specified for debugging
output. You can turn off these messages with the no debug ip ospf spf command.
OSPF: Running dijksttra for area 1
OSPF: Adding routing table entry for transit network 207.95.6.146
OSPF: adding stub networks for area 1
OSPF: New routing table:
OSPF: ---Entry #1
OSPF: destination 1.1.1.0, mask 255.255.255.0, type 0
OSPF: area 0.0.0.1 path cost 1, type 0
OSPF: next hop router 15.212.4.123, outgoing interface loopback 22
OSPF: advertising router 1.1.1.1
OSPF: ---Entry #2
OSPF: destination 4.4.4.0, mask 255.255.255.0, type 0
OSPF: area 0.0.0.1 path cost 1, type 0
OSPF: next hop router 16.148.4.123, outgoing interface loopback 22
OSPF: advertising router 1.1.1.1
(remaining routing table entries omitted)
Syntax: [no] debug ip ospf spf
Possible values: N/A
Default value: N/A
debug ip pim <address>
Displays information about PIM related traffic. Messages are displayed when hello, join, graft, and prune
messages are sent or received.
EXAMPLE:
ProCurveRS# debug ip pim 239.255.162.6
After you enter this command, messages such as the following appear at the destination specified for debugging
output. You can turn off these messages with the no debug ip pim <address> command.
PIM: send prune e7, source 1.1.1.2 group 239.255.162.6 nbr 2.2.2.1
PIM: rcvd prune e7, Source 1.1.1.2 group 239.255.162.6
PIM: send graft e7, source 1.1.1.2 group 239.255.162.6 nbr 2.2.2.1
PIM: rcvd graft e7, source 3.3.3.1 group 239.255.162.6
Syntax: [no] debug ip pim [<ip-addr>]
Possible values: Valid PIM group address.
Default value: N/A
debug ip pim events
Displays messages when PIM events, including deleting and adding group entries, occur.
EXAMPLE:
ProCurveRS# debug ip pim events
