Diagnostic Guide for ProCurve 9300/9400 Series Routing Switches
Possible values: N/A
Default value: N/A
debug ip tcp memory
The debug ip tcp memory command causes messages to be displayed when memory is allocated or deallocated
to the internal TCP buffers.
EXAMPLE:
ProCurveRS# debug ip tcp memory
For example, when a user establishes a Telnet session with the device, an then terminates it, messages such as
the following appear at the destination specified for debugging output. You can turn off these messages with the
no debug ip tcp memory command.
TCP TCB ALLOCATED 210de822
TCP SEND BUFFER ALLOCATED 2111ec80
TCP SEND QUEUE BUFFER ALLOCATED 210d88dc
TCP SEND BUFFER ALLOCATED 2113695c
TCP SEND QUEUE BUFFER ALLOCATED 210d9714
TCP SEND BUFFER ALLOCATED 2111f838
TCP SEND QUEUE BUFFER ALLOCATED 210d894c
TCP SEND BUFFER ALLOCATED 21117174
TCP SEND QUEUE BUFFER ALLOCATED 210d8444
TCP SEND BUFFER ALLOCATED 210f4aac
TCP SEND QUEUE BUFFER ALLOCATED 210d6fb4
TCP SEND BUFFER ALLOCATED 210f5088
TCP SEND QUEUE BUFFER ALLOCATED 210d6fec
TCP SEND BUFFER FREED 2111ec80
TCP QUEUE BUFFER FREED 210d6fec
TCP RECEIVE QUEUE BUFFER ALLOCATED 210d6fec
TCP RECEIVE BUFFER ALLOCATED 21151530
TCP RECEIVE BUFFER FREED 21151530
TCP QUEUE BUFFER FREED 210d6fec
TCP RECEIVE QUEUE BUFFER ALLOCATED 210d6fec
TCP RECEIVE BUFFER ALLOCATED 21151530
TCP RECEIVE BUFFER FREED 21151530
TCP QUEUE BUFFER FREED 210d6fec
TCP TCB FREED 210de822
Syntax: [no] debug ip tcp memory
NOTE: Output from this command appears only on the console or syslog. The output is suppressed when sent
to a Telnet or SSH session.
Possible values: N/A
Default value: N/A
debug ip tcp packet
Displays information about received and sent TCP packets.
EXAMPLE:
ProCurveRS# debug ip tcp packet
3 - 24 June 2005
