ProCurve 9304m Diagnostics Manual page 27

debug ip igmp
Displays IGMP related information.
EXAMPLE:
ProCurveRS# debug ip igmp
After you enter this command, messages such as the following appear at the destination specified for debugging
output. You can turn off these messages with the no debug ip igmp command.
IGMP: send message to 1.1.1.1 port ethernet 1 type 17 size 28
IGMP: send query to all port. type 17 port ethernet 7 ver 2
IGMP: rcvd v2 membership report from 1.1.1.2 group address 239.255.162.1 port ethernet
1 size 8
IGMP: rcvd membership query from 2.2.2.100 group address 0.0.0.0 port ethernet 7 size 8
IGMP: rcvd pim from 2.2.2.100 group address 16.0.0.0 port ethernet 7 size 12
debug ip msdp alarms
Displays information about MSDP alarms.
EXAMPLE:
ProCurveRS# debug ip msdp alarms
After you enter this command, messages such as the following appear at the destination specified for debugging
output. You can turn off these messages with the no debug ip msdp alarms command.
MSDP: S=xxxxxxx P=0 Initiate Transport Connection to MSDP peer
Syntax: [no] debug ip msdp alarms
Possible values: N/A
Default value: N/A
debug ip msdp events
Displays messages when significant MSDP events occur.
EXAMPLE:
ProCurveRS# debug ip msdp events
After you enter this command, messages such as the following appear at the destination specified for debugging
output. You can turn off these messages with the no debug ip msdp events command.
MSDP: 172.16.2.4: Closing session
MSDP: 172.16.2.4: Peer back to IDLE state
MSDP: (172.16.2.4) START peer
MSDP: 172.16.2.4: Closing session
MSDP: 172.16.2.4: Peer back to IDLE state
MSDP: Originating SA
MSDP: (172.16.2.4) START peer
MSDP: 172.16.2.4: TCP Connection to Remote Peer is Open
MSDP: 172.16.2.4: MSDP-TCP Connection opened
MSDP: 172.16.2.4: TCP_OPEN DONE, State 4
MSDP: Remote Peer closed TCP connection
Syntax: [no] debug ip msdp events
Possible values: N/A
Default value: N/A
June 2005
HP Diagnostic Command Reference
3 - 13
