  • Page 1 WWW.INFOPULSAS.LT / info@infopulsas.lt LTE Industrial Router LR77 v2 USER MANUAL...
  • Page 2 Website www.advantech-bb.com c 2019 Advantech B+B SmartWorx s.r.o. No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photography, recording, or any information storage and retrieval system without written consent. Information in this manual is subject to change without notice, and does not represent a commitment on the part of Advantech B+B SmartWorx.
  • Page 3 Source codes under GPL licence are available free of charge by sending an email to: techSupport@advantech-bb.com. Please see http://ep.advantech-bb.cz/devzone for more information. Advantech B+B SmartWorx s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic Document No. MAN-0014-EN, revision from January 17, 2019. Released in the Czech Republic.

  • Page 4: Table Of Contents

    LR77 v2 Contents 1 Safety Instructions 2 WEEE directive 3 Router Description 4 Contents of Package 5 Router Design 5.1 Router versions ........5.2 Delivery identification .
  • Page 5 LR77 v2 7.1 Basic parameters ........7.2 Standards and regulations .
  • Page 6 LR77 v2 List of Figures Contents of package ....... . . Front panel LR77 v2B(G) .
  • Page 7 LR77 v2 List of Tables Router versions ........Delivery identification .

  • Page 8: Safety Instructions

    LR77 v2 1. Safety Instructions Please, observe the following instructions: The router must be used in compliance with all applicable international and national laws and in compliance with any special restrictions regulating the utilization of the router in prescribed applications and environments. To prevent possible injury and damage to appliances and to ensure compliance with all relevant provisions, use only the original accessories.

  • Page 9: Weee Directive

    LR77 v2 2. Product Disposal Instructions The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive was in- troduced to ensure that electrical/electronic products are recycled using the best available recovery techniques in order to minimize impact on the environment. This product contains high quality materials and components which can be recycled.

  • Page 10: Router Description

    LR77 v2 3. Router Description LTE router LR77 v is used to wirelessly connect various equipments and devices via Eth- ernet interface 10/100 to the Internet or Intranet. Thanks to high data transfer speed of up to 100 Mbps (download) and upload speed up to 50 Mbps it is an ideal wireless solution for traffic and security camera systems, individual computers, LAN networks, automatic teller machines (ATM) and other self-service terminals, etc.

  • Page 11: Contents Of Package

    LR77 v2 4. Contents of Package Basic delivered set of router includes: router, power supply, crossover UTP cable, up to three external antennas, clip for the DIN rail, paper start guide. Figure 1: Contents of package Temperature range for power supply is reduced to 0 C to +40 C! As optional accessories can also be supplied the following expansion ports (one for Basic version or two for Full version): RS232, RS485/422, MBUS, ETHERNET, CNT, SWITCH, WIFI, WMBUS or SDH.

  • Page 12: Router Design

    LR77 v2 5. Router Design 5.1 Router versions LR77 v2 router is supplied in the following versions (see table below). All versions are available in plastic or metal box according to customer requirements. Router versions Router Box LR77 v2B(G) Plastic LR77 v2B(G) SL Metal LR77 v2B L45...

  • Page 13: Label Examples

    LR77 v2 5.2 Delivery identification Trade name Order code Description LR77 v2B(G) BB-LR2Buuvw1y-zzzz Basic version LR77 v2B(G) SL BB-LR2Buuvw2y-zzzz Basic version in the metal box LR77 v2F(G) BB-LR2Fuuvw1y-zzzz Full version LR77 v2F(G) SL BB-LR2Fuuvw2y-zzzz Full version in the metal box LR77 v2B L45 BB-LR2B74vw1y-zzzz Basic version...

  • Page 14: Type Of Port #1

    LR77 v2 5.3 Order codes 5.3.1 Order code structure Order code has following structure: BB-LR2tuuvwxy-zzzz , where: t = router version, B = basic version (1x SIM slot, 1x extension port), F = full version (2x SIM slot, 2x extension port), uu = type of cellular module, 71 = Gemalto LTE module, 72 = Sierra wireless LTE module,...

  • Page 15: Type Of Port #2

    LR77 v2 Letter "w" – port #2 Port type Letter "w" in code none RS232 RS485 RS422 MBUS WiFi WMBUS Table 4: Type of port #2 Letter "x" – type of the router box Type of router box Letter "x" in code Plastic Metal Table 5: Type of router box...

  • Page 16: Specific Variation

    LR77 v2 Letter "z" – specific variation Variation Letter "z" in code basic variation not specified v2F3 (2x SMA, 1x R-SMA: ANT + GPS + WiFi, router does not have diversity antenna) v2F4 (2x SMA, 1x R-SMA: ANT + DIV + WMBUS, router has R-SMA antenna connector for WMBUS) v2F5 (3x SMA: ANT + GPS + WiFi, router does not have diver- sity antenna)

  • Page 17: Basic Dimensions Of Plastic Box (Bottom And Front View)

    LR77 v2 5.4 Basic dimensions of the router box 5.4.1 Plastic box Figure 9: Basic dimensions of plastic box (bottom and front view) 5.4.2 Metal box Figure 10: Basic dimensions of metal box (bottom and front view)

  • Page 18: Space Around Antennas (Plastic)

    LR77 v2 5.5 Mounting recommendations possibility to be put on a work surface, DIN rail EN 60715 with included plastic or metal clip. For the most of applications with a built-in router in a switch board it is possible to recognize two kinds of environments: no public and industry environment of low voltage with high interference, public environment of low voltage without high interference.

  • Page 19: Cable Routing (Plastic)

    LR77 v2 For every cables we recommend to bind the bunch, we recommend for this use: – Length of the bunch (combination of power supply and data cables) can be maxi- mum 1.5 m. If the length of data cables exceeds 1.5 m or in the event of, the cable leads towards the switch –...

  • Page 20: Default Position Of Plastic And Metal Din Rail Clip

    LR77 v2 5.6 Removal from the DIN rail The DIN rail clip is suitable for a DIN rail according to EN 60715 standard only. The default position of plastic or metal rail clip, which is used for mounting the router on a DIN rail, is shown in the following figure.

  • Page 21: Front Panel Lr77 V2F(G)

    LR77 v2 5.7 Description of the front panel On the front panel is the following: Caption Connector Description 2-pin Connector for the power supply. RJ45 Connector for connection into the local computer network. PORT1 RJ45 Connector for expansion port RS232, RS458/422, MBUS, ETHERNET, CNT or SWITCH.

  • Page 22: Status Indication

    LR77 v2 5.7.1 Status indication About router status inform eight LED indicators on the front panel. ETH port, PORT1 and PORT2 have two additional LEDs that provide information about port status. Caption Color State Description Green Blinking Router is ready. Starting of the router.

  • Page 23: Power Connector

    LR77 v2 5.7.2 Power connector PWR Panel socket 2-pin. Pin number Signal mark Description VCC(+) Positive pole of DC supply voltage (+9 to +36 V DC) GND(-) Negative pole of DC supply voltage Table 12: Connection of power connector Figure 20: Power connector Power supply for router is required between +9 V to +36 V DC supply.

  • Page 24: Connecting Of The Antenna

    LR77 v2 5.7.3 Antenna connector ANT, DIV and GPS (alternatively WIFI or WMBUS) Main and diversity antennas are connected to the router using the SMA connector on the front panel. Full version of the router also contains the third SMA antenna connector, through which the additional antenna can be connected (if WIFI expansion port is used, this connector is reverse –...

  • Page 25: Ejected Sim Holder

    LR77 v2 5.7.4 SIM card reader The SIM card reader for 3 V and 1,8 V SIM cards is placed on the front panel of the router. For getting the router to work is necessary to insert an activated SIM card with an unblocked PIN code.

  • Page 26: Ethernet Connector

    LR77 v2 5.7.5 Ethernet Port ETH Panel socket RJ45. Signal mark Description Data flow direction TXD+ Transmit Data – positive pole Input/Output TXD- Transmit Data – negative pole Input/Output RXD+ Receive Data – positive pole Input/Output — — — — RXD- Receive Data –...

  • Page 27: Port1 Cable Connection

    LR77 v2 5.7.6 PORT1 The PORT1 is equipped on customer’s request with one of the offered expansion ports: RS232 MBUS RS485 RS422 SWITCH (together with PORT2) ETHERNET Description and examples of expansion ports connection can be found in user’s guide for corresponding expansion port.

  • Page 28: Port2 Cable Connection

    LR77 v2 Plug cable for the second expansion port into the RJ45 connector labeled as PORT2 (see figure below). Figure 27: PORT2 cable connection 5.7.8 USB Port Panel socket USB-A. Signal mark Description Data flow direction +5 V Positive pole of 5 V DC supply voltage, 0.5 A USB data - USB data signal –...

  • Page 29: O Connector

    LR77 v2 5.7.9 I/O Port Panel socket 3-pin. Signal mark Description Data flow direction BIN0 Binary input Input Signal ground OUT0 Binary output Output Table 15: Connection of I/O port Figure 29: I/O connector I/O user interface is designed for processing of binary input and control (setting) binary output.

  • Page 30: Connection Of Input And Output To The Router

    LR77 v2 Example of a circuit describing connection of binary input and output to the router: Figure 31: Connection of input and output to the router...

  • Page 31: Router Reset

    LR77 v2 5.7.10 Reset When PWR LED starts flashing on the front panel, it is possible to restore the default con- figuration of the router by pressing the RST button on the front panel. After pressing this button the default configuration is restored and then router reboots (green LED will be on). For pressing the RST button could be used a narrow screwdriver.

  • Page 32: First Use

    LR77 v2 6. First Use 6.1 Connecting the router before first use Before putting the router into operation it is necessary to connect all components which are required to run your applications. Don’t forget to insert SIM card. The router can not operate without connected antenna, SIM card and power supply. If the antenna is not connected, router can be damaged.

  • Page 33: Entering The Ip Address Of The Router

    LR77 v2 6.2 Start The router is put into operation when the power supply is connected to this router. By default, the router will automatically start to log on to the default APN. DHCP server will start to assign addresses for devices on the Ethernet port ETH0. Router behavior can be changed via the web interface.

  • Page 34: Router Web Interface

    LR77 v2 After successfully entering login information user gains access to the router via his internet browser. Figure 36: Router web interface A detailed description of the router settings via the Web interface can be found in the document Configuration manual for v2 routers. 6.3.2 Configuration over Telnet For status monitoring, configuration and administration of the router can be also used Telnet.

  • Page 35: Technical Parameters

    LR77 v2 7. Technical Parameters 7.1 Basic parameters LR77 v2 Temperature range Operating -40 C to +75 C Storage -40 C to +85 C Humidity Operating 0 to 95 % relative humidity non condensing Storage 0 to 95 % relative humidity non condensing Altitude Operating 2000 m / 70 kPa...

  • Page 36: Standards And Regulations

    LR77 v2 7.2 Standards and regulations The router complies with the following standards and regulations. 7.2.1 Versions LR77 v2B and LR77 v2F Versions LR77 v2B and LR77 v2F Telecom and emission ETSI EN 301 511 v9.0.2, ETSI EN 301 908-1 v5.2.1, ETSI EN 301 908-2 v5.2.1, ETSI EN 301 908-13 v5.2.1 ETSI EN 301 489-1 v1.9.2 Safety...

  • Page 37: Versions Lr77 V2B L45

    LR77 v2 Continued from previous page Versions LR77 v2B L45 ETSI EN 301 489-1 V2.1.1 (2016-11), Draft ETSI EN 301 489- 19 V2.1.0 (2017-03), Draft ETSI EN 301 489-52 V1.1.0 (2016- 11), ETSI EN 301 489-17 V3.1.1 (2017-02), ETSI EN 301 489-3 V2.1.1 (2017-03) Safety EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013...

  • Page 38: Technical Parameters Of Module

    LR77 v2 7.3 Technical parameters of module 7.3.1 Versions LR77 v2B and LR77 v2F LTE module for versions LR77 v2B and LR77 v2F LTE parameters Bit rate 100 Mbps (DL) / 50 Mbps (UL), UE CAT. 3 3GPP rel. 9 standard Supported bandwidths: 5 Mhz, 10 Mhz, 20 Mhz Supported frequencies: 800 / 900 / 1800 / 2100 / 2600 MHz HSPA+ parameters...

  • Page 39: Lte Module Supports 450 Mhz

    LR77 v2 Continued from previous page LTE module for versions LR77 v2BG and LR77 v2FG UMTS parameters PS bit rate 384 kbps (DL) / 384 kbps (UL) CS bit rate 64 kbps (DL) / 64 kbps (UL) W-CDMA FDD standard Supported frequencies: 900 / 1800 / 2100 MHz GPRS/EDGE parameters Bit rate 237 kbps (DL) / 59,2 kbps (UL)

  • Page 40: Technical Parameters Of Gps

    LR77 v2 7.4 Technical parameters of GPS GPS is not available when the router is equipped with the LTE module 450 MHz! GPS specifications Antenna 50 Ohms – active Protocols NMEA 0183 v3.0 Frequency 1575.42 MHz Sensitivity Tracking: -161 dBm Acquisition (Assisted): -158 dBm Acquisition (Standalone): -145 dBm Acquisition time...

  • Page 41: Other Technical Parameters

    LR77 v2 7.5 Other Technical Parameters Other technical parameters 32b ARM microprocessor 0.25 DMIPS per MHz Flash memory 16 MB DDR SDRAM 64 MB M-RAM 128 kB Table 25: Other technical parameters 7.6 Technical parameters of I/O port Binary input and output Input/Output Binary input Reed contact with trigger level 1.3 up to 1.4 V...

  • Page 42: Recommended Literature

    LR77 v2 8. Recommended Literature Advantech B+B SmartWorx: Start guide for v2 routers, Advantech B+B SmartWorx: Configuration manual for v2 routers, Advantech B+B SmartWorx: User’s manual – Expansion port RS232, Advantech B+B SmartWorx: User’s manual – Expansion port RS485/422, Advantech B+B SmartWorx: User’s manual –...

  • Page 43: Troubleshooting

    9. Troubleshooting If you cannot connect to the router from your PC, your network card may be configured in such a way that it is not possible to connect to the router. Take one or more of the following steps in order to solve the problem: Make sure your PC’s network card is configured to obtain the IP address form the DHCP server (by default the DHCP server is running in the router).
  • Page 44 In a private APN it is not recommended to get the DNS settings from operator (on "Mobile WAN" page) Go to "System Log" page in "Status" section and observe where the error occurs. I cannot connect from the Internet to the device behind the router. I have NAT enabled.
  • Page 45 Serial communication is not working. Verify that the router model supports serial communications. Also verify the serial communication settings. To do so, open the router’s configuration menu via the web browser, select the appropriate "Expansion Port" from "Configuration" part of the menu and verify the settings.

  • Page 46: Customers Support

    During cleaning of the router do not use aggressive chemicals, solvents and abrasive cleaners! Hereby, Advantech B+B SmartWorx s.r.o. company declares that the radio equipment narrated in this user’s guide is in compliance with EU Directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following internet address:...
