Chapter 4 Install Stratix 5410 Switches

Wire the Power Source

116
3. Insert the power supply module into the slot, and gently push it in.
When inserted correctly, the power-supply module is flush with the
switch.
4. Use a ratcheting torque screwdriver to torque each screw to 0.904...1.13
N•m (8...10 lb•in).
To wire the power source, follow these steps.
1. Turn power off at the AC and DC circuits.
IMPORTANT If the power is not off at the AC or DC circuit breaker, do not touch
2. To loosen the captive screw on the power input terminal, use a Phillips
screwdriver.
IN
OU
ANA .Tim eCo de
28
Con sole
Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
the power-input terminal.
TOD
Alar m
32557-M
32558-M
