The following table lists the pinouts for the console port, RJ45-to-DB-25
female DTE adapter, and the console device.
The RJ45-to-DB-25 female DTE adapter is not supplied with the switch.
Table 174 - Pinouts with DB-25 Pin
Switch Console Port (DTE)
Signal
RTS
DTR
TxD
GND
GND
RxD
DSR
CTS

PoE Port Cable Specifications

For PoE ports, use a Category 5 (Cat 5) cable with a distance of up to 100 m
(328 ft).
Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Cables and Connectors
RJ45-to-DB-25 Terminal Adapter
DB-25 Pin
5
6
3
7
7
2
20
4
Appendix D
Console Device
Signal
CTS
DSR
RxD
GND
GND
TxD
DTR
RTS
