Allen-Bradley Stratix 5400 User Manual page 501

Table 164 - Stratix 5400 Port Numbering (continued)
Cat. No. Description
1783-HMS4EG8CGR 12-port (4 Gigabit ports; 4 Gigabit combo ports; 4 Gigabit
PoE/PoE+ ports) managed switch; Layer 3 firmware
Port Numbering on Switch Labels
1
2
3
4
5
6
7
8
9
10
11
12
Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Port Numbering Appendix C
Port Numbering in config.txt Text File
Gi1/1
Gi1/2
Gi1/3
Gi1/4
Gi1/5
Gi1/6
Gi1/7
Gi1/8
Gi1/9
Gi1/10
Gi1/11
Gi1/12
