Table 133 - Input Data Type (20-port Gb switches) (continued)
AB:STRATIX_5400_20PORT_GB_MANAGED:I:0
Member Name
AllPortsUtilization
PortGi1_1Utilization
PortGi1_2Utilization
PortGi1_3Utilization
PortGi1_4Utilization
PortGi1_5Utilization
PortGi1_6Utilization
PortGi1_7Utilization
PortGi1_8Utilization
PortGi1_9Utilization
PortGi1_10Utilization
PortGi1_11Utilization
PortGi1_12Utilization
PortGi1_13Utilization
PortGi1_14Utilization
PortGi1_15Utilization
PortGi1_16Utilization
PortGi1_17Utilization
PortGi1_18Utilization
PortGi1_19Utilization
PortGi1_20Utilization
MajorAlarmRelay
MinorAlarmRelay
MulticastGroupActive
Table 134 - Output Data Type (20-Gb port switches)
AB:STRATIX_5400_20PORT_GB_MANAGED:O:0
Member Name
AllPortsDisabled
PortGi1_1Disable
PortGi1_2Disable
PortGi1_3Disable
PortGi1_4Disable
PortGi1_5Disable
PortGi1_6Disable
PortGi1_7Disable
PortGi1_8Disable
Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Type Default Display
Style
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
SINT Decimal
BOOL Decimal
BOOL Decimal
DINT Binary
Type Default Display
Style
BOOL Decimal
BOOL Decimal
BOOL Decimal
BOOL Decimal
BOOL Decimal
BOOL Decimal
BOOL Decimal
BOOL Decimal
BOOL Decimal
Data Types Appendix A
Valid Values
AlarmRelay:0
AlarmRelay:1
Valid Values
DisablePort:0
DisablePort:1
DisablePort:2
DisablePort:3
DisablePort:4
DisablePort:5
DisablePort:6
DisablePort:7
DisablePort:8
