Chapter 2 Get Started

Express Setup Overview

30
When you first install the switch, use Express Setup to perform these initial
setup tasks:
• Assign the switch an initial IP address. You can then access the switch
through the IP address for more configuration.
• Run the global macro to set initial configuration parameters, as
described on page

Express Setup Requirements

Multi-mode and single-mode versions of Express Setup are available depending
on your switch and IOS version:
• With IOS version 15.2(4)EA3 or later, all switches use multi-mode
Express Setup, as described on
• With IOS version 15.2(4)EA or earlier, all switches use single-mode
Express Setup, as described on
Multi-mode Express Setup enables you to configure network settings in either
Device Manager or the Studio 5000 Logix Designer® application. To configure
network settings via the Logix Designer application, you must have the Add-on
Profile (AOP) for Stratix® switches, version 11.01.xx or later.
Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
43.
page 34.
page 38.
