Table 158 - Input Data Types (continued)

PortGi1_1Threshold

PortGi1_2Threshold

PortFa1_1Threshold

PortFa1_2Threshold

PortFa1_3Threshold

PortFa1_4Threshold

PortFa1_5Threshold

PortFa1_6Threshold

PortFa1_7Threshold

PortFa1_8Threshold

PortFa2_1Threshold

PortFa2_2Threshold

PortFa2_3Threshold

PortFa2_4Threshold

PortFa2_5Threshold

PortFa2_6Threshold

PortFa2_7Threshold

PortFa2_8Threshold

PortFa3_1Threshold

PortFa3_2Threshold

PortFa3_3Threshold

PortFa3_4Threshold

PortFa3_5Threshold

PortFa3_6Threshold

PortFa3_7Threshold

PortFa3_8Threshold

AllPortsUtilization

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017

Indicates that unicast, multicast, or broadcast threshold limit has

been exceeded on a particular port.

1 = Threshold exceeded

The sum of the percentage of the bandwidth utilized of all ports on
