Synchronize the SD Card via the Logix Designer Application
You can synchronize the SD card to either the configuration file or the entire
image.
In the navigation pane, click SD Flash Sync.
Table 23 - SD Flash Sync Fields
Field
SD Flash Status
Synchronization Status
Copy from SD Flash to Switch
Copy from Switch to SD Flash
Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Description
Indicates whether the SD card is present and the status. of the card
Indicates whether the configuration files and the IOS are synchronized or
unsynchronized.
Choose from these options:
• Copy Configuration
• Copy IOS Image
Choose from these options:
• Copy Configuration
• Copy IOS Image
Get Started
Chapter 2
67
