Chapter 7 Configure Switch Features
Table 42 - DLR Port Choices for Stratix 5700 and ArmorStratix 5700 Switches
Switch
1783-BMS10CGP Fa 1/7
1783-BMS10CGN Fa 1/7
1783-BMS12T4E2CGL Fa 1/15
1783-BMS12T4E2CGP Fa 1/15
1783-BMS12T4E2CGNK Fa 1/15
1783-BMS20CL Fa 1/15
1783-BMS20CA Fa 1/15
1783-BMS20CGL Fa 1/15
1783-BMS20CGP Fa 1/15
1783-BMS20CGN Fa 1/15
1783-BMS20CGPK Fa 1/15
1783-ZMS4T4E2TGP Fa 1/7
1783-ZMS8T8E2TGP Fa 1/15
1783-ZMS4T4E2TGN Fa 1/7
1783-ZMS8E82TGN Fa 1/15
216
Fa 1/8 Gi 1/1 Gi 1/2
Fa 1/8 Gi 1/1 Gi 1/2
Fa 1/16 Gi 1/1 Gi 1/2
Fa 1/16 Gi 1/1 Gi 1/2
Fa 1/16 Gi 1/1 Gi 1/2
Fa 1/16
Fa 1/16
Fa 1/16 Gi 1/1 Gi 1/2
Fa 1/16 Gi 1/1 Gi 1/2
Fa 1/16 Gi 1/1 Gi 1/2
Fa 1/16 Gi 1/1 Gi 1/2
Fa 1/8 Gi 1/1 Gi 1/2
Fa 1/16 Gi 1/1 Gi 1/2
Fa 1/8 Gi 1/1 Gi 1/2
Fa 1/16 Gi 1/1 Gi 1/2

DLR Considerations

IMPORTANT Depending on your network architecture, DLR topology limitations can exist.
Some switch capabilities are not supported on DLR-enabled ports.
Unsupported capabilities include, but are not limited to, the following:
• EtherChannels
• NAT
• REP
• MST/PVST/RPVST
• FlexLinks
• 802.1x Security
• Multiple VLANs
• Smartport roles, except for Multiport Automation Device or None
DLR ports function only as access ports and not trunk ports.
Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Port
Fa 1/17 Fa 1/18
Fa 1/17 Fa 1/18
Fa 1/17 Fa 1/18
Fa 1/17 Fa 1/18
Fa 1/17 Fa 1/18
Fa 1/17 Fa 1/18
Make sure to validate your DLR topology within the larger network before
production use.
Fa 1/19 Fa 1/20
Fa 1/19 Fa 1/20
