Table 98 - Stratix 5400 Port Status Indicators
Mode Status
Status In Status mode, the port status indicators show the connection and activity status of the port. Status mode is the default mode. You can choose Status mode via
the View pull-down menu in Device Manager. You can also choose Status mode by pressing the Disp. Mode button on the physical switch until all mode status
indicators on the switch turn off.
Off
Solid green
Flashing green and off
Alternating green and
amber
Solid amber
Duplex In Duplex mode, the port status indicators show the Duplex mode (Full-duplex or Half-duplex) of the ports. The 10/100/1000 ports operate only in Full-duplex
mode.
Off
Solid amber
Solid green
Speed In Speed mode, the port status indicators show the operating speed of the ports.
Off
Solid amber
Solid green
Flashing green
PRP In PRP mode, the port status indicators show the status of Parallel Redundancy Protocol (PRP). To configure PRP, see
Off
Solid green
DLR—Not functional as of the current release.
Power/PoE In Power or PoE mode, the port status indicators show the status of PoE on switch models with PoE capability.
The Power mode available via the View pull-down menu in Device Manager is the same as the PoE mode available via the Disp. Mode button on the physical
switch.
Off
Solid green
Flashing green and amber
Flashing amber
Description
No link present on the port.
Port link; no activity.
Link is active and healthy.
There is a fault or error on the link.
The port is disabled.
The port is not operating.
The port is operating in Half-duplex mode.
The port is operating in Full duplex mode.
The port is not operating.
The port is operating at 10 Mbps.
The port is operating at 100 Mbps.
The port is operating at 1000 Mbps.
PRP is disabled or not in use on the port.
PRP is active on the port.
PoE is disabled on the port.
PoE is enabled on the port. The switch port is providing power.
PoE is denied because it exceeds the power capacity of the switch.
PoE is denied because it exceeds the configured power limit for the switch port.
Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Monitor the Switch Chapter 8
page 297.
