Inserting and Removing Firepower 8000 Series Network Modules
Figure B-4
Stacking Configuration Considerations
A stacking module combines the resources of two or more identically configured appliances. See
Firepower 8000 Series Stacking Module, page 3-9
models support stacking. Configure the modules as follows for stacked devices:
•
•
•
•
See
the "8000 Series Device Stacking" chapter in the Firepower Management Center Configuration Guide
for information about managing device stacks with your Firepower Management Center.
Included Items
Your module assembly kit includes a T8 Torx screwdriver and one or more of the following modules:
•
•
•
•
Use this dual-slot NetMod only on the 40G-capacity Firepower 8250 or Firepower or AMP 8350. If you
Note
need to upgrade your device, see the Cisco 8000 Series Device 40G Capacity Upgrade Guide.
•
Firepower 82xx Family and 83xx Family Primary Device
You can use a device stack as you would a single device in your deployment, with a few exceptions.
If you have Firepower 8000 Series devices in a high-availability pair, you cannot stack a device
high-availability pair or a device in a high-availability pair.
When replacing NetMods on a stacked configuration, complete all procedures on the secondary
units first, then perform any replacements on the primary unit.
Install NetMods on the primary device only.
Install one stacking module on the primary device for each stacked secondary device, and one
stacking module on each secondary device.
Using Devices in a Stacked Configuration, page 3-10
quad-port 1000BASE-T copper configurable bypass NetMod. For more information, see
1000BASE-T Copper Configurable Bypass NetMod, page
quad-port 1000BASE-SX fiber configurable bypass NetMod. For more information, see
1000BASE-SX Fiber Configurable Bypass NetMod, page
dual-port 10GBASE (MMSR or SMLR) fiber configurable bypass NetMod. For more information,
see
Dual-Port 10GBASE (MMSR or SMLR) Fiber Configurable Bypass NetMod, page
dual-port 40GBASE-SR4 fiber configurable bypass NetMod. For more information, see
40GBASE-SR4 Fiber Configurable Bypass NetMod, page
quad-port 1000BASE-T copper non-bypass NetMod. For more information, see
1000BASE-T Copper Non-Bypass NetMod, page
About Firepower 8000 Series Modules
for information about which Firepower 8000 Series
for complete information about stacking. See
2-13.
2-13.
2-16.
2-18.
Firepower 8000 Series Hardware Installation Guide
Quad-Port
Quad-Port
2-15.
Dual-Port
Quad-Port
