802.11 Utilization

The 802.11 Channel Utilization results include the top three
channels in each band (2.4 GHz and 5 GHz) with the highest
802.11 utilization. The channels are displayed with their
measured utilization percentage and rating of
Warning, or Fail, based on the 802.11 Interference
threshold.
Figure 16. 802.11 Channel Utilization Results

Non-802.11 Utilization

The Non-802.11 Channel Utilization results include the top
three channels in each band (2.4 GHz and 5 GHz) with the
most non-802.11 interference, e.g., noise.
Pass,
The channel utilization percentage is displayed along with a
rating symbol:
non-802.11 Interference threshold.
The channel usage will vary depending on the time of day,
based on the number of clients connected to the network,
the amount of interference from devices, such as
microwaves or video cameras, etc.
30
Using AutoTest to Diagnose Your Network Health
Pass, Warning, or Fail, based on the
