Wireless Specifications

Specification compliance
Wi-Fi Connectivity
Operating frequencies
NOTE: These are the center
frequencies of the channels that
the AirCheck G2 Tester
supports.
IEEE 802.11a, 802.11b, 802.11g, 802.11n, 802.11ac
802.11a, 802.11b, 802.11g, 802.11n, 802.11ac
Frequencies of channels received
NOTE: The Tester receives on all of the frequencies in every country.
2.4 GHz band: 2.412 – 2.484 GHz (channel 1 to channel 14)
5 GHz band: 5.170 – 5.320 GHz, 5.500 – 5.700 GHz, 5.745 – 5.825 GHz (channels
34, 36, 38, 40, 42, 44, 46, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128,
132, 136, 140, 144, 149, 153, 157, 161, 165)
Frequencies of channels transmitted:
NOTE: The Tester transmits only on the frequencies allowed in the country for which
it is currently configured.
2.4 GHz band
802.11b: 2.412 – 2.484 GHz (channel 1 to channel 14)
802.11g/n 20 MHz BW (HT20): 2.412
802.11n 40 MHz BW (HT40): 2.422 – 2.462 GHz (includes all combinations of
legal, bonded pairs of channels)
2.472 GHz (channel 1 to channel 13)
–
91
Specifications and Compliance
