The Channel Details Screen

Figure 12. Channel Details Screen
The Channel Details screen shows the following detailed
information about the selected channel:
Screen Title: The channel number and frequency of the
channel being monitored.
APs: The number of access points discovered on the channel.
Touch this row to open the Access Points list screen with
the APs filtered for the selected Channel.
NOTE: This field shows the number of physical access
points if Group virtual access points is selected.
Otherwise, individual BSSIDs are shown.
Settings," page 76.
Clients: The number of Wi-Fi clients discovered on the
channel. Touch this row to open the Clients list screen
with the clients filtered for the selected Channel.
Channel Utilization (line graph): Shows 802.11 (blue) vs.
non-802.11 (gray) utilization of the channel over time. The
two horizontal bars below the line graph show in real time
the percentage of 802.11 utilization vs. non-802.11 utilization
of the channel. Very busy channels can make the network
slow or affect connectivity.
Signal Level: The real-time signal level (in dBm) of the
strongest AP signal on the channel.
23
Viewing Channel Usage
See "802.11
