Xilinx LogiCORE MicroBlaze Product Manual page 28

Table 4-3: Internal I/O Module Parameters Settings (Cont'd)
Parameter Name
C_IO_LOWADDR
C_IO_MASK
C_LMB_AWIDTH
C_LMB_DWIDTH
C_INTC_HAS_FAST
C_INTC_ADDR_WIDTH
1. Value depends on C_MEMSIZE: 12 for 4096, 13 for 8192, 14 for 16384, 15 for 32768, and 16 for 65536.
.
Table 4-4: Internal LMB_v10 Parameters Settings (ILMB)
Parameter Name
C_LMB_NUM_SLAVES
C_LMB_AWIDTH
C_LMB_DWIDTH
C_EXT_RESET_HIGH
Table 4-5: Internal LMB_v10 Parameters Settings (DLMB)
Parameter Name
C_LMB_NUM_SLAVES
C_LMB_AWIDTH
C_LMB_DWIDTH
C_EXT_RESET_HIGH
Table 4-6: Internal LMB BRAM IF Controller Parameters Settings (ILMB Controller)
Parameter Name
C_BASEADDR
C_HIGHADDR
C_MASK
C_LMB_AWIDTH
C_LMB_DWIDTH
C_ECC
MicroBlaze Micro Controller System v1.3
PG048 December 18, 2012
Feature/Description
LMB I/O Module I/O bus address
LMB I/O Module I/O bus address space decode mask
LMB address bus width
LMB data bus width
Use fast interrupt mode
Interrupt address width
Feature/Description
Number of LMB slaves
LMB address bus width
LMB data bus width
Level of external reset
Feature/Description
Number of LMB slaves
LMB address bus width
LMB data bus width
Level of external reset
Feature/Description
LMB BRAM base address
LMB BRAM high address
LMB decode mask
LMB address bus width
LMB data bus width
Implement error correction and detection
All other ECC as well AXI and PLB parameters are don't
care
www.xilinx.com
Chapter 4: Customizing and Generating the Core
Value
0xFFFFFFFF
0xC0000000
32
32
1
(1)
12 - 16
Value
1
32
32
1 = active-High reset
Value
2
32
32
1 = active-High reset
Value
0
Value of MicroBlaze
MCS Parameter
C_MEMSIZE
0x80000000
32
32
0 = No ECC
27
