Table 4-2: Internal MicroBlaze Parameters Settings (Cont'd)
Parameter Name
(1)
C_*EXCEPTION*
C_OPCODE_0x0_ILLEGAL
C_USE_STACK_PROTECTION
C_DEBUG_ENABLED
C_NUMBER_OF_PC_BRK
C_NUMBER_OF_RD_ADDR_BRK
C_NUMBER_OF_WR_ADDR_BRK
C_INTERRUPT_IS_EDGE
C_EDGE_IS_POSITIVE
C_FSL_LINKS
C_USE_ICACHE
C_USE_DCACHE
C_USE_MMU
C_USE_INTERRUPT
C_USE_EXT_BRK
C_USE_EXT_NM_BRK
C_USE_BRANCH_TARGET_CACHE Enable branch target cache
1. * denotes wildcard and represents any number of characters or numbers.
Table 4-3: Internal I/O Module Parameters Settings
Parameter Name
C_BASEADDR
C_HIGHADDR
C_MASK
C_IO_HIGHADDR
MicroBlaze Micro Controller System v1.3
PG048 December 18, 2012
Feature/Description
No exceptions are used
MDM Debug interface
Number of hardware breakpoints
Number of read address watchpoints
Number of write address watchpoints
Level/Edge interrupt
Negative/positive edge interrupt
Number of stream interfaces (FSL or AXI)
All other stream parameters are don't
care
Instruction cache
All other instruction cache parameters
are don't care
Data cache
All other data cache parameters are don't
care
Memory management
All other MMU parameters are don't care
Enable interrupt handling
Enable external break handling
Enable external non-maskable break
handling
All other BTC parameters are don't care
Feature/Description
LMB I/O Module register base address
LMB I/O Module register high address
LMB I/O Module register address space decode mask
LMB I/O Module I/O bus base address
www.xilinx.com
Chapter 4: Customizing and Generating the Core
Value
0
Value of MicroBlaze MCS
parameter
C_DEBUG_ENABLED
Value of MicroBlaze MCS
parameter
C_DEBUG_ENABLED
0
0
0
1
0
0
0
0
2
Value of MicroBlaze MCS
parameter
C_DEBUG_ENABLED
Value of MicroBlaze MCS
parameter
C_DEBUG_ENABLED
0
Value
0x80000000
0x8000FFFF
0xC0000000
0xC0000000
