Chapter 1: Product Introduction

Hardware Specifications

Main Chipset
• Intel EG20T
®
CPU
• Intel Atom™ E640 1.0GHz
®
Memory
• On board 1GB DDR2 800MHz
Expansion
• Mini PCIe socket (USB) x 1 (for 3.5G module)
• 1 x GPS module
• Mini PCIe socket (PCIe + USB + SATA) x 1 (for WLAN module)
I/O Interfaces - Front
• On Screen Display Buttons x 5 Power On/ Off Volume Control (+/-)
Brightness Control (+/-)
• Light Sensor
• 2 x LED indicators
• 2 x Built-in Speakers (1W)
Copyright © 2011 NEXCOM International Co., Ltd. All rights reserved
I/O Interfaces - Lateral Side
• 1 x Line-in
• 1 x Line-out
• 1 x USB
• 1 x SIM slot
• 1 x Power Button
• 1 x Reset Button
Bottom Side
• 1 x DB9 male connector (RS-232)
• 1 x DB37 female connector (1x LAN ; 2x USB ; 1x RS232 ; 1 x RS422/485 ;
6 x GPIO ; 1 x CAN)
• 6~36V Wide Range DC power input
• 1 x SMA connector for GPS antenna
Expandable Storage
• 1 x mSATA
Power Management
• Selectable boot-up & shut-down voltage for low power protection
• HW design ready for 8-level delay time on/off at user's self configuration
• Power on/off ignition, software detectable
• Supports S3/S4 suspend mode ; wake on RTC/ SMS
