Features

•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Scalable 4K @ 60 Hz videowall processing for display systems of any size —
Quantum Ultra supports videowalls up to 36 screens in size from a single Quantum
device. Additional processors can be configured and operated as a single system to
accommodate larger videowalls.
Modular architecture accommodates a variety of input and output
arrangements — The Quantum Ultra card frame can be populated with input and
output cards selected to match source and display requirements for efficient system
design.
Future-ready 400 Gbps HyperLane video bus delivers unparalleled real-
time performance — The Extron HyperLane video bus has a total throughput of
400 Gbps, easily accommodating the high-bandwidth demands of large videowalls
displaying many simultaneous HD and 4K sources.
Supports 4K on one, two, or four connections — Quantum Ultra offers the
convenience of managing 4K video as a single, dual, or quad-path signal, for flexibility
when working with 4K sources, peripherals, and displays.
Manage multiple videowalls with varying resolutions and screen
arrangements from a single Quantum device — Videowalls of varying output
resolutions and orientation can all be supported with a single chassis.
Designed for 24/7, mission-critical environments — Quantum Ultra provides a
high performance, high reliability display processing solution for monitoring valuable
infrastructure and assets with maximum uptime.
Integrates easily into a diverse array of 4K environments such as lobbies,
auditoriums, and simulations — Quantum Ultra is optimized for use with 4K
displays, windowing large numbers of high-resolution sources across multiple displays
with resolutions up to 3840x2160 or greater.
Extron Vector 4K scaling engine — The Vector 4K scaling engine is specifically
designed for critical-quality 4K imagery, with best-in-class image upscaling and
downscaling.
Advanced 4:4:4 signal processing — 4:4:4 signal processing maintains color
accuracy and fine picture detail.
Seamless transitions — Seamless cut and fade through black transition effects
are available when switching between presets, delivering fast, glitch-free, and
professional-looking presentations for any application.
Display locally stored images — Image file types, including JPEG, PNG, and
bitmaps can be uploaded to the Quantum Ultra for use as backgrounds or displayed
as source windows.
Keying and Alpha channel support for image files — User-definable level or
color keying for image files allows transparent backgrounds for pictures, logos, and
messages. Alpha channel and transparency are also supported.
6U, 10-slot Card Frame — The 6U, 10-slot Quantum Ultra card frame supports any
combination of input and output cards for I/O sizes from 36x4 to 4x36, or anything
in-between.
Removable storage drives — The operating system and data storage drives are
easily removable to accommodate security management procedures.
Solid-state, write-protected operating system drive — The operating system
runs from a solid-state, write-protected drive for reliable, long-term operation.
Quantum Ultra Videowall Processing System • Introduction 2
