Hot-swappable, dual-redundant Extron EverLast power supplies — Hot
•
swappable dual-redundant power supplies with two AC power inputs provide reliable
operation and maximum up-time.
• Indicator LEDs — Front panel LEDs indicate fan and power supply status.
• HDMI input card supports signals up to 4K @ 60 Hz — The IN4HDMI
four-channel input card accepts signals from 1024x768 to 2048x1080 and
1920x1200 at 60 Hz. Dual-channel mode supports two single path 4K @ 30 Hz
signals, while single-channel mode supports one dual-path or quad path 4K @ 60 Hz
signal. When used with HDCP-compliant displays and the HDMI output card,
HDCP 1.4-encrypted sources can be displayed on the videowall.
HDMI and DTP output cards support signals up to 4K @ 60 Hz — The
•
OUT4HDMI and OUT4DTP four-channel output cards deliver signals from 1024x768
to 2048x1080 and 1920x1200 at 60 Hz. Dual-channel mode supports two single
path 4K @ 30 Hz signals, while single-channel mode supports one dual-path or quad
path 4K @ 60 Hz signal.
• Decodes and displays multiple streamed VNC sources — Quantum Ultra can
display streamed content sourced from PCs running a Virtual Network Computing –
VNC server application. Multiple VNC streams can be presented simultaneously on
the videowall for collaborative desktop sharing from local or remote PCs.
• Selectable HDMI to DVI Interface Format Correction — The Quantum Ultra
enables or disables embedded InfoFrames and sets the correct color space for
proper connection to HDMI and DVI displays.
• Up to 64 video and graphic windows per output card — Quantum Ultra offers
extensive windowing capabilities, with the ability to display up to 64 video, image, and
clock windows from each output card.
• Powerful window management and source scaling capabilities — Sources can
be windowed, layered, and positioned anywhere on the video display, from 1/32 of
the native source resolution to 32 times the output resolution.
• User-definable window borders and text labels enhance presentation and
simplify source identification — Custom color borders with rounded corners, drop
shadows, and transparency can be applied to any window type. A border can be set
to flash to draw attention to the source window. Border titles and overlay text can be
applied to a window and dynamically updated from the control system to indicate a
change in the source name, type, status, or classification level.
Source rotation — Sources can be rotated in 90-degree increments, providing
•
flexible and creative presentation options for live content as well as internally stored
images.
Supports portrait and landscape screen orientation — Videowalls with a mixture
•
of portrait and landscape displays can be simultaneously managed from a single
Quantum device.
Output overlap for edge-blended applications — This feature supports
•
edge-blended applications by providing redundant image data for the blended regions
of the projection system.
• Mullion compensation for flat-panel displays — Adjustable compensation
extends the displayed image "behind" screen bezels, accurately presenting sources
which span multiple displays.
• HDCP compliance — Ensures display of content-protected media and
interoperability with other HDCP-compliant devices.
• SpeedSwitch Technology — Delivers virtually instantaneous switching speeds for
HDCP-encrypted content.
