Maximum windows per output card
This section discusses the maximum number of source windows that each output
card can support, at different resolutions and refresh rates. A total of 64 windows are
supported per output card.
Example 1: All source windows on one output channel
In this example, 64 windows have been assigned to output channel (connector) 1.1.
No additional windows are available for output channels 1.2, 1.3, and 1.4. (Additional
windows can be assigned to other cards.)
1
Output Channel 1.1
Windows 1 through 64 (all available windows)
Figure 21.
Example 2: All Source Windows distributed evenly among all four output
channels
1
16
Output Channel 1.1
Windows 1 through 16
Figure 22.
Example of All Available Windows Assigned to One Output Channel
17
32
Output Channel 1.2
Windows 17 through 32
Example of All Available Windows Distributed Evenly Among the Four
Output Channels.
Quantum Ultra Videowall Processing System • Installation
8
64
33
48
Output Channel 1.3
Windows 33 through 48
49
64
Output Channel 1.4
Windows 49 through 64
