User-selectable HDCP authorization — Allows individual inputs to appear HDCP
•
compliant or non-HDCP compliant to the connected source, which is beneficial if the
source automatically encrypts all content when connected to an HDCP-compliant
device. Protected material is not passed in non-HDCP mode.
• HDCP Visual Confirmation provides a green signal when encrypted content
is sent to a non-compliant display — A green window with an alert message is
displayed when HDCP-encrypted content is transmitted to a non-HDCP compliant
display, providing immediate visual confirmation that protected content cannot be
viewed on the display.
• Picture controls — Controls are provided for brightness, contrast, detail, horizontal
and vertical sizing, horizontal and vertical positioning, zoom, and overscan.
• Internal video test patterns for calibration and setup — Quantum Ultra offers
several dynamically-generated video test patterns to facilitate proper system setup
and calibration of display devices.
• Transmits up to four outputs at distances up to 330 feet (100 meters) over
a shielded CATx cable (OUT4DTP) — Reduces system complexity when output
extension is required for driving videowall displays up to 330 feet (100 meters) away
from the Quantum Ultra unit.
Selectable DTP, XTP, and HDBaseT output modes (OUT4DTP) — Allows
•
selection of the type of twisted pair technology best suited for the application.
• Power insertion enables remote powering of DTP receivers (OUT4DTP) —
12 V DC insertion at the OUT4DTP card enables the DTP receivers to be powered
over the twisted pair connections, eliminating the need for separate power supplies at
the remote units. Requires one PS 124 per OUT4DTP card.
RS 232 insertion from the Ethernet control port (OUT4DTP) — System level
•
device control to all remote locations via the Quantum Ultra control port, providing
comprehensive control of endpoints and attached devices without needing additional
equipment.
• Encrypted data connection between Quantum Ultra and configuration PC —
SSL encryption provides a secure connection between Quantum Ultra and the PC
running the Extron Videowall Configuration Software.
• Digitally-signed, secure firmware upgrades — Firmware updates are digitally
signed and transferred across an encrypted connection for secure system upgrades.
• Physical and IP port management — The physical USB, RS-232, and Ethernet
ports can be disabled independently, as can FTP, HTTP, and other IP ports.
• Event logging — A system event log is maintained as a locally stored file with a
user-definable maximum size, and can be downloaded directly from the processor.
Password protected operating system — Access to the Quantum Ultra operating
•
system is protected with a user-definable password.
Service maintenance alerts — System administrators can be notified of fan or
•
power supply failure, or when recommended operating temperature is exceeded.
• Power Save Mode — The unit can be placed in a low power standby state to
conserve energy when not in use.
• Easy-to-use configuration and control software — The easy-to-use Videowall
Configuration Software - VCS reduces configuration and preset programming time
with a task-oriented, intuitive interface.
• Direct control via RS-232 and Ethernet — Locally-stored configuration file allows
direct connection between the control system and Quantum Ultra.
