Serial Configuration Commands
Appendix D — Serial Configuration Commands
The following table is a list of all the available serial configuration commands (also
called "K" commands) in alphabetical order. These commands are also listed at the
beginning of each chapter, as applicable. For utility (operational) commands see
mary of Utilities Commands" on page 5-2.
Table A-7 MS-3 CCD Serial Configuration Commands
Command Title
Host Port Parameters
Host Protocol
Preamble
Postamble
Number of Symbols
Time Between Identical
Decodes
Trigger Mode
Serial Trigger Character
Start Character
Stop Character
No Decode Timeout
Decodes Before Timeout
Noread Message
Automatic Gain Control
Lighting Intensity
Filter Mode
Code 39
Code 128/EAN
Interleaved 2 of 5
Codabar
UPC/EAN
Code 93
Industrial 2 of 5
MSI Code
Plessey
A-10
MS-3 CCD Reader User's Manual
Communications
<K100,baud,parity,stop bits,data bits>
<K140, protocol>
<K141,preamble status,preamble>
<K142,postamble status,postamble>
Read Cycle
<K222, number of symbols>
<K503,TBID>
<K200,trigger mode>
<K201, serial trigger character>
<K229,start trigger character>
<K230, stop trigger character>
<K220, no decode timeout>
<K221, number before output>
< , ,noread message>
K714 status
<K522,shutter speed,minimum speed,maximum speed>
<K523,percent lighting>
<K524,filter mode,filter list>
Symbology
<K470, status,check digit status,check digit output sta-
tus,unused,unused,minimum symbol length,full ASCII set>
<K474, status,unused,minimum symbol length,1,1,unused,application
record separator character>
<K472, status,check digit status,check digit output status,symbol length
#1,symbol length #2>
<K471, status,unused,start & stop output status,unused,symbol length
status,symbol length,check digit type,check digit status
>
put status
<K489,UPC-A status,UPC-E status,EAN-8 status,EAN-13 sta-
tus,supplemental status,supplemental 2 status,supplemental 5 sta-
tus,UPC-A as EAN-13, UPC-E as A,EAN-8 as EAN-13>
<K475, status,unused,minimum length>
<K488, status,check digit status,check digit output status,format,symbol
length #1,symbol length #2>
<K486, status,check digit mode,check digit output status,unused,mini-
mum symbol length>
<K487, status,check digit output status,unused,minimum symbol
length>
Format
,
check digit out-
"Sum-
