Chapter
2
With Microscan's ESP (Easy Setup Program), configuration changes can be made in
the ESP menus, then sent and saved to your reader. The user can also send serial com-
mands to the reader via the ESP's Terminal window.
This section includes connecting parameters and options for communicating by the aux-
iliary port and various interfaces.
Note: When assigning characters in user-defined fields, the characters
can only be entered through embedded menus, not through ESP or serial commands.
Note: Default settings for establishing communications are:
Baud = 9600
Even
Parity =
Stop Bits = One
Data Bits = Seven
Flow Control = None
Note: You can learn the current setting of any parameter by inserting a question mark
after the number, as in
Communications
Communications by ESP .........................................................................2-2
Communications By Serial Command .....................................................2-2
Preamble .................................................................................................2-6
Postamble ................................................................................................2-7
<K100?> To see all "K" commands, send <K?>.
Chapter Contents
MS-3 CCD Reader User's Manual
NULL <> and ,
2-1
