Reader Setup
Filter Selection
When Filter Mode is set for Automatic, you can compare filter success rates in an
actual scanning application by sending a
Each filter will output its number of successes. In
are shown in succession from left to right. Filter 1 acquires 95 reads, the others 0. The
choice is obvious. When you enable Filter 1 in Filter List only, the other filters are
omitted and the number of captures and decodes per second should significantly
improve.
Filter 0 Filter 2
Filter 1
3-16
MS-3 CCD Reader User's Manual
<C>
Filter 3

Figure 3-3 Filter Selection

command from the Terminal window.
figure 3-3 the four filters (0 through 3)
