Microscan MS-3 User Manual page 82

Connectivity
Figure A-5 IC-332
READER Pinouts
Pin
Host 232
No.
1 Power + VDC
2
3
4 Power/Signal Ground
5
6
7 Not used by MS-3 CCD
8 Not used by MS-3 CCD
9 Trigger
10
11 Not used by MS-3 CCD
12 Not used by MS-3 CCD
13 Chassis Ground
14 Not used by MS-3 CCD
15 Not used by MS-3 CCD
A-6
MS-3 CCD Reader User's Manual
In/Out
Out
TXD In
RXD Out
NC
RTS In
In
Out
Out
CTS Out
In
Out
In
Figure A-6 IC-332
EXTERNAL Pinouts (to IB-131)
Pin
Host 232
No.
1 Power + 10 to 28 VDC
2 TXD
3 RXD
4 Power/Signal Ground
5 Trigger (-)
6 RTS
7 Not used by MS-3 CCD
8 Not used by MS-3 CCD
9 Trigger (+)
10 CTS
11 Not used by MS-3 CCD
12 Not used by MS-3 CCD
13 Chassis Ground
14 Not used by MS-3 CCD
15 Not used by MS-3 CCD
In/Out
In
Out
In
In
Out
Out
In
In
In
In
Out
Out
