Interleaved 2 of 5

Usage: It is has been popular because it is the most dense symbol for printing
numeric characters less than 10 characters in length; however Microscan
does not recommend this symbology for any new applications because of
inherent problems such as truncation.
Definition: A dense, continuous, self-checking, numeric symbology. Characters are
paired together so that each character has five elements, two wide and
three narrow, representing numbers 0 through 9, with the bars repre-
senting the first character and the interleaved spaces representing the
second character. (A check digit is highly recommended.)
Important: You must set Symbol Length in order to decode I 2/5 sym-
bols.
Interleaved 2 of 5 Status
Serial Cmd: <K472,
#1,symbol length #2>
Default: Disabled
Options: 0 = Disabled
Check Digit Status (Interleaved 2 of 5)
Usage: It is typically not used but can be enabled for additional security in appli-
cations where the host requires redundant check digit verification.
Definition: An error correcting routine in which the check digit character is added.
Serial Cmd: <K472, status,check digit
length #1,symbol length #2>
Default: Disabled
Options: 0 = Disabled
Check Digit Output Status (Interleaved 2 of 5)
Definition: When enabled, a check digit character is sent along with the bar symbol
data for added data security.
Serial Cmd: <K472,
length #1,symbol length #2>
Default: Disabled
Options: 0 = Disabled
status,check digit status,check digit output status,symbol length
1 = Enabled
status,check digit output status,symbol
1 = Enabled
status,check digit status,check digit output
1 = Enabled
Chapter 4 Symbologies
status,symbol
MS-3 CCD Reader User's Manual
4-7
