4.1.3

Controller

Figure 88
• Under normal conditions, the LEDs should be illuminated constant green.
• If a problem is detected, the color of the relevant LED will change to amber.
Figure 87. LEDs on Controller
Figure 88. Controller LED Indicators
Enclosure fault
Firmware status
4.1.4

HDD (Hard Disk Drive)

Figure 89
• Under normal conditions, the LEDs should be illuminated constant green.
• If a problem is detected, the color of the relevant LED will change to amber.
Figure 89. HDD LED Indicators
Identifier
Enclosure fault
Drive fault
0 0 7 - 5 5 3 3 - 0 0 1
describes the controller LED
Firmware Status LED
Identifier Location
Front enclosure
Rear enclosure
Power Rear enclosure
Identify Rear enclosure
describes the fault LED status when an HDD has failed.
Location
Enclosure front
Enclosure front
status.
(Figure 87)
EXPANSION CLI
RESE
LINK
Color
Amber ON - IO fault detected
ON - InfiniteStorage 6120 is ready to be accessed
Blinks - firmware is loading
Green
OFF - InfiniteStorage 6120 is NOT ready to be
accessed
ON - power is applied to controller
Green
OFF - power is NOT applied to controller
ON - SES identify command is received
Blue
OFF - SES identify command is NOT received
Color Status
Amber ON - drive fault
Amber ON - drive fault
Status LED Indicators
Identify LED
Power LED
SPEED
Status
63
