3.1

Managing the InfiniteStorage 6120

The InfiniteStorage 6120 provides a set of tools that enable administrators to centrally manage the
network storage and resources that handle business-critical data. These include configuration
management, performance management, and firmware update management.
NOTE : The command descriptions given in this user guide only apply to firmware
version 1.0.3.3.xxxx. To access the most up-to-date commands, use the CLUI's online help
feature.
3.1.1

Management Interface

SAN management information for the InfiniteStorage 6120 can be accessed locally through a serial
interface or remotely through SSH.
NOTE : An InfiniteStorage 6120 may only have one active login (serial or SSH) per
controller at any given time.
Locally via Serial Interface
Any RS-232 terminal or terminal emulator (such as Hyperterminal) can be used to configure and
monitor the InfiniteStorage 6120.
1. Connect the supplied mini-jack cable to the port labeled CLI on Controller 1
Connect the other end of the cable to a serial port on a standard PC.
Figure 45. CLI Port on Controller
2. Load a serial console program (such as HyperTerminal, minicom, or screen) and use the
following settings for the serial connection:
• Bits per second:
• Data bits:
• Parity:
• Stop bits:
• Flow control:
3. Once connected, hit the <Enter> key to bring up the password prompt. Enter the password:
user.
Remotely via SSH
To configure and monitor the InfiniteStorage 6120 remotely, connect the controller to your Ethernet
network. Please refer to Section 3.6, "Remote Management of InfiniteStorage 6120" for further
information on how to set up the controller's network interface.
0 0 7 - 5 5 3 3 - 0 0 1
EXPANSION CLI
115,200
8
None
1
None
Managing the InfiniteStorage 6120
(Figure 45)
CLI Connector
LINK SPEED
.
35
