2.3.2

Drive Layout

Figure 23
enclosure ID and slot number as illustrated.
The InfiniteStorage 6120 supports mixing SAS and SATA drives within the same enclosure. For
most efficient airflow and reduced vibrations, SAS drives should be placed in the front of the
enclosure (lower slot numbers) while SATA drives should be placed in the rear of the enclosure
(higher slot numbers).
2.3.3

Initial Configuration via RS-232

The InfiniteStorage 6120 can be configured and administered either via serial connection (using the
supplied mini-jack cable) or via Ethernet connection using SSH. However, in order to use the SSH
connection, it is first necessary to configure the network settings on each controller. This can only
be done using the serial interface as described in the next subsection.
2.3.3.1

Serial Interface Configuration

1. Connect the supplied mini-jack cable to the port labeled CLI on Controller 1
Connect the other end of the cable to a serial port on a standard PC.
Figure 24. CLI Port on Controller
2. Load a serial console program (such as HyperTerminal, minicom, or screen) and use the
following settings for the serial connection:
• Bits per second:
• Data bits:
• Parity:
• Stop bits:
• Flow control:
3. Once connected, hit the <Enter> key to bring up the password prompt. Enter the password:
user.
0 0 7 - 5 5 3 3 - 0 0 1
shows the layout of drives in an InfiniteStorage 6120. Drives are always referenced by
Figure 23. InfiniteStorage 6120 Drive Layout
DRIVE 1 DRIVE 13 DRIVE 25
DRIVE 2 DRIVE 14 DRIVE 26
DRIVE 3 DRIVE 15 DRIVE 27
DRIVE 4 DRIVE 16 DRIVE 28
DRIVE 5 DRIVE 17 DRIVE 29
Front
DRIVE 6 DRIVE 18 DRIVE 30
of
DEM 2B DEM 2A
AUX DRIVE
Chassis DEM 4A
DRIVE 7 DRIVE 19 DRIVE 31
DRIVE 8 DRIVE 20 DRIVE 32
DRIVE 9 DRIVE 21 DRIVE 33
DRIVE 10 DRIVE 22 DRIVE 34
DRIVE 11 DRIVE 23 DRIVE 35
DRIVE 12 DRIVE 24 DRIVE 36
Serial EXPANSION
115,200
8
None
1
None
Configuring the InfiniteStorage 6120
DRIVE 37 DRIVE 49
DRIVE 38 DRIVE 50
DRIVE 39 DRIVE 51
DRIVE 40 DRIVE 52
DRIVE 41 DRIVE 53
DRIVE 42 DRIVE 54
DEM 1B DEM 1A
DEM 4B DEM 3A DEM 3B
DRIVE 43 DRIVE 55
DRIVE 44 DRIVE 56
DRIVE 45 DRIVE 57
DRIVE 46 DRIVE 58
DRIVE 47 DRIVE 59
DRIVE 48 DRIVE 60
CLI Connector
CLI
LINK SPEED
.
(Figure 24)
24
