2.3.9

Creating Spare Pools

The InfiniteStorage 6120 supports the concept of a spare pool. A spare pool contains physical disks
that can be used as spare disks in one or more storage pools.
In the event of drive failure, a drive that is assigned to a spare pool is automatically swapped into the
storage pool to replace the failed drive. A rebuild then occurs immediately, reducing the possibility
of data loss due to additional drive failures.
Spare pools can be shared by storage pools or dedicated to a particular , in which case the spare disks
will only be used by the designated storage pool. After a spare pool is created, you will need to select
drive(s) from the unassigned pool and assign it to the spare pool.
NOTE : For maximum performance, create spare pools using drives with the same
characteristics as those drives within the storage pool(s) for which they are designated to
spare. The characteristics include items like SAS/SATA, capacity, and RPM.
To create a spare pool:
1. At the CLUI prompt, type: CREATE SPARE_POOL
A message is displayed to indicate whether the new spare pool creation was successful.
Figure 37. CREATE SPARE POOL Example Screen
2. Assign disk(s) to the spare pool, enter command:
ASSIGN PHYSICAL_DISK <disk-id> TO_POOL <pool-id>
where <disk-id> is the index name of the disk to be added.
To view the list of unassigned disks, enter command SHOW UNASSIGNED_POOL
PHYSICAL_DISK
A message is displayed to indicate whether the disk has been added to the spare pool
Figure 38. Assign Physical Disk to Spare Pool Example Screen
RAID$ assign physical_disk 0x004e to_pool 6
PHYSICAL_DISK 78 OID=0x20b6004e assigned to POOL 6 OID=0x19bc0006STATUS='Success'
3. Use the CREATE SPARE_POOL and ASSIGN PHYSICAL_DISK commands to create more
spare pools as needed.
If you need to delete a disk from the spare pool, enter command ASSIGN PHYSICAL_DISK
<disk-id> TO_POOL 0x1800ffff
To delete a spare pool, enter command DELETE SPARE_POOL <pool-id>
4. To view the list of configured spare pool(s), enter command SHOW SPARE_POOL *
Figure 39. Show Spare Pool Example Screen (1)
0 0 7 - 5 5 3 3 - 0 0 1
RAID$ create spare_pool
SPARE POOL 6 OID=0x19bc0006 create STATUS='Success'
RAID$ show spare_pool *
OID: 0x19bc0006 Index: 0x0006 Name: 19bc0006
Configuring the InfiniteStorage 6120
(Figure 37)
.
(Figure 38)
.
(Figure 39)
