2.3.3.2

Configure Network Settings

To enable SSH access to each controller, the network settings must be configured as follows:
1. Enter command: UI SET NETWORK_INTERFACE LOCAL IP_ADDRESS=<ip_address>
IP_MASK=<netmask> IP_GATEWAY=<gateway>
where <ip_address> is an address appropriate to the local network. The netmask and gateway
values can also be entered
Figure 25. Set Network Interface Example
RAID$ ui set network_interface local ip_address=10.32.31.31
ip_mask=255.255.240.0 ip_gateway=10.32.16.2
NETWORK_INTERFACE 0 set with STATUS='Success'
2. To verify the new settings, enter command
UI SHOW NETWORK_INTERFACE LOCAL *
Figure 26. Show Network Interface Settings
3. Switch the serial cable to the CLI port on Controller 2 and repeat the above steps to enter a
different IP address for Controller 2.
4. Enter command SHUTDOWN SUBSYSTEM RESTART to restart the controllers and make the
changes take effect.
2.3.4 Setting System Time & Date
The system time and date for the InfiniteStorage 6120 are factory-configured for the U.S. Pacific
Standard Time (PST) zone. If you are located in a different time zone, you need to change the settings
so that the time stamps for all events are correct.
To display the current system time
ALL_ATTRIBUTES
Figure 27. Show Current System Time
To change the date and time to March 1, 2009 2:15:32 pm, for example, type:
SET SUBSYSTEM DATE_AND_TIME=2009:3:1:14:15:32
0 0 7 - 5 5 3 3 - 0 0 1
(Figure 25)
RAID$ ui show network_interface local *
Network device id 0
address 10.32.31.31
netmask 255.255.240.0
gateway 10.32.16.2
(Figure 27)
RAID$ show subsystem all_attributes
RP Subsystem Name:
UID: 0x0000000000000000
Subsystem Time: Fri Jan 30 16:48:55
Time zone: 0 minutes
DST offset: 0 minutes
Locate Dwell Time: 120 seconds
Mirror Synch: NA
Configuring the InfiniteStorage 6120
.
:
(Figure 26)
, enter command SHOW SUBSYSTEM
2009
